webform 整合 autofac

Autofac

安裝 Autofac.Web

1	Install-Package Autofac.Web -Version 6.0.0

先在 web.config 加上這段 , 官方寫推薦 IIS6 & IIS7 的設定都加 , 我懶得加

<system.webServer>
  <!-- This section is used for IIS7 -->
  <modules>
    <add
      name="ContainerDisposal"
      type="Autofac.Integration.Web.ContainerDisposalModule, Autofac.Integration.Web"
      preCondition="managedHandler"/>
    <add
      name="PropertyInjection"
      type="Autofac.Integration.Web.Forms.PropertyInjectionModule, Autofac.Integration.Web"
      preCondition="managedHandler"/>
  </modules>
</system.webServer>

建立類別 Box

public class Box
{
	public string Name { get; set; }
}

建立 interface IRepo 及 BoxRepo

IRepo

public interface IRepo
{
	List<Box> GetAll();
}

BoxRepo

  public class BoxRepo : IRepo
  {
//理論上這邊會寫 ado.net or dapper or ef 的程式碼
      public List<Box> GetAll()
      {
          return new List<Box> {
              new Box { Name = "Car 1" } ,
              new Box { Name = "Car 2" } ,
              new Box { Name = "Car 3" } ,
          };
      }
  }

接著找到 Global 實現這個介面 IContainerProviderAccessor

public class Global : HttpApplication, IContainerProviderAccessor
{
	// Provider that holds the application container.
	static IContainerProvider _containerProvider;

	// Instance property that will be used by Autofac HttpModules
	// to resolve and inject dependencies.
	public IContainerProvider ContainerProvider
	{
		get { return _containerProvider; }
	}

	void Application_Start( object sender, EventArgs e )
	{
		// Build up your application container and register your dependencies.
		var builder = new ContainerBuilder();
		builder.RegisterType<BoxRepo>().As<IRepo>().InstancePerRequest();

		//builder.RegisterType<BoxService>().As<IBoxService>().
		//	UsingConstructor(typeof(IRepo)).InstancePerRequest();
		// ... continue registering dependencies...

		// Once you're done registering things, set the container
		// provider up with your registrations.
		_containerProvider = new ContainerProvider( builder.Build() );


		// Code that runs on application startup
		RouteConfig.RegisterRoutes( RouteTable.Routes );
		BundleConfig.RegisterBundles( BundleTable.Bundles );
	}
}

然後撰寫 Page 的程式碼 , 至此 Repository 就可以直接拿出資料了 , 可是實際上應該要多加個 Service 層比較優 , 不過老案子可能會沒這些

public partial class _Default : Page
{
    public IRepo BoxRepo { get; set; }
    //public IBoxService BoxService { get; set; }
    protected void Page_Load( object sender, EventArgs e )
    {
        var boxs = BoxRepo.GetAll();
        boxs.ForEach( x => Console.WriteLine(x.Name));
    }
}

接著建立 IBoxService

public interface IBoxService : IRepo
{
    Box GetFirst();
}

然後實現他 , 這裡用建構子注入 IRepo

public class BoxService : IBoxService
{
    private readonly IRepo _boxRepo;
    public BoxService( IRepo boxRepo )
    {
        _boxRepo = boxRepo;
    }
    public List<Box> GetAll()
    {
        return _boxRepo.GetAll();
    }

    public Box GetFirst()
    {
        return _boxRepo.GetAll().FirstOrDefault();
    }
}

一樣回到 Global 加入 DI 設定的程式碼 , 看看要不要明確設定 UsingConstructor 不這樣寫應該可以

1 2	builder.RegisterType<BoxService>().As<IBoxService>() .UsingConstructor(typeof(IRepo)).InstancePerRequest();

接著調整 Page 就搞定了

public partial class _Default : Page
{
    //public IRepo BoxRepo { get; set; }
    public IBoxService BoxService { get; set; }
    protected void Page_Load( object sender, EventArgs e )
    {
        //var boxs = BoxRepo.GetAll();
        //boxs.ForEach( x => Console.WriteLine(x.Name));

        var boxs = BoxService.GetAll();
        var box = BoxService.GetFirst();

    }
}

整合 NLog

webform

安裝 NLog

1	Install-Package NLog -Version 4.7.13

接著在 Global 註冊 NLog

1	builder.RegisterType<Logger>().As<ILogger>().InstancePerRequest();

但是會炸 error , 因為他的建構子是 protected internal

1	Autofac.Core.Activators.Reflection.NoConstructorsFoundException: 'No accessible constructors were found for the type 'NLog.Logger'.'

最無腦爆力法直接繼承 Logger 然後送他一個 public 的建構子即可

public class MyLogger : Logger
{
	public MyLogger(){}
}

Global 註冊改這樣

1	builder.RegisterType<MyLogger>().As<ILogger>().InstancePerRequest();

另外如果想要在自己的物件也用屬性注入的話修改這樣 , 因為老 code 很容易有建構子地獄發生 , 所以插 Log 改用屬性注入 , 不然寫到哭

1	builder.RegisterType<BoxService>().As<IBoxService>().PropertiesAutowired().InstancePerRequest();

最後 Default Page 修改這樣就搞定了

public partial class _Default : Page
{
    public IBoxService BoxService { get; set; }

    public ILogger Logger { get; set; }
    protected void Page_Load( object sender, EventArgs e )
    {
        Logger.Info( "test log default page" );
        //var boxs = BoxRepo.GetAll();
        //boxs.ForEach( x => Console.WriteLine(x.Name));

        var box = BoxService.GetFirst();
        //Logger.Info(box.Name);
        var boxs = BoxService.GetAll();
    }
}

不然就是參考老外多包一個代理用的中間層

public interface ILoggerService<T>
{
    void Info(string message);

    void Debug(string message);
}

public class LoggerService<T> : ILoggerService<T>
{
    public ILogger logger { get; set; }

    public LoggerService()
    {
        logger = LogManager.GetLogger(typeof(T).FullName);
    }

    public void Debug(string message)
    {
        logger.Debug(message);
    }

    public void Info(string message)
    {
        logger.Info(message);
    }
}

最後註冊進去就搞定了

1	builder.RegisterGeneric(typeof(LoggerService<>)).As(typeof(ILoggerService<>)).InstancePerRequest();

webapi

想要在 Global 的 Application_Error 讓 Log 有作用 , 生命週期要選 InstancePerLifetimeScope 才生效

1	builder.RegisterType<MyLogger>().As<ILogger>().InstancePerLifetimeScope();

測試 Application_Error

protected void Application_Error(object sender, EventArgs e)
{
	var rawUrl = Request.RawUrl;
	var ex = Server.GetLastError();

	var logger = _containerProvider.ApplicationContainer.Resolve<ILogger>();
	logger.Error(ex);


	Debug.WriteLine("RawUrl: {0}", rawUrl);
	Debug.WriteLine("Ex: {0}", ex.Message);
	Debug.WriteLine("StackTrace: {0}", ex.StackTrace);

}

可是 web api 不會直接走 Application_Error , 要加上 filter , 但因為跟 autofac 進行整合 , 所以要加上 IAutofacExceptionFilter 參考官網

public class LoggingActionFilter : IAutofacExceptionFilter
{
	readonly ILogger _logger;

	public LoggingActionFilter(ILogger logger)
	{
		_logger = logger;
	}

	public Task OnExceptionAsync(HttpActionExecutedContext actionExecutedContext, CancellationToken cancellationToken)
	{
		_logger.Error(actionExecutedContext.Exception);
		return Task.FromResult(0);
	}
}

接著設定 DI 屬性注入

1
2
3

builder.Register(c => new LoggingActionFilter(c.Resolve<ILogger>()))
	.AsWebApiExceptionFilterForAllControllers()
	.InstancePerRequest();

注意還要有設定這段才會正確生效

1 2	var config = GlobalConfiguration.Configuration; builder.RegisterWebApiFilterProvider(config);

如果不想用 Global 的方式的話 , 其實也可以直接繼承 ExceptionFilterAttribute 然後 override OnException
特別注意到 namespace System.Web.Http.Filters

public class LogExceptionFilterAttribute : ExceptionFilterAttribute
{
	public ILogger Logger { get; set; }

	public override void OnException(HttpActionExecutedContext context)
	{
		Logger.Error(context.Exception);
	}
}

注意一樣要設定 builder.RegisterWebApiFilterProvider(config); , 接著掛載 Attribute 到 Controller 上即可

[LogExceptionFilter]
public class HaController : ApiController
{
	[HttpGet]
	[Route("ha")]
	public string Ha()
	{
		throw new Exception("Ha");
		return "HA";
	}
}

改用 Microsoft.Extensions.Logging

首先安裝 NLog.Config NLog.Extensions.Logging NLog.Web
參考大神及 NLog官方
舊版 web api 忘了怎麼寫可以參考老外 or 這篇

注意引用命名空間 using Microsoft.Extensions.Logging;

接著設定 Autofac 整合 , 修改 Application_Start

protected void Application_Start()
{
	AreaRegistration.RegisterAllAreas();
	GlobalConfiguration.Configure(WebApiConfig.Register);
	FilterConfig.RegisterGlobalFilters(GlobalFilters.Filters);
	RouteConfig.RegisterRoutes(RouteTable.Routes);
	BundleConfig.RegisterBundles(BundleTable.Bundles);

	//把 NLog 的 Provider 新增進去
	var loggerFactory = new LoggerFactory();
	loggerFactory.AddProvider(new NLogLoggerProvider());

	var builder = new ContainerBuilder();

	//這行是必須的
	builder.RegisterInstance(loggerFactory).As<ILoggerFactory>().SingleInstance();
	//用泛型註冊
	builder.RegisterGeneric(typeof(Logger<>)).As(typeof(ILogger<>));


	builder.RegisterType<TestAttribute>().PropertiesAutowired();
	builder.RegisterType<LogExceptionFilterAttribute>().PropertiesAutowired();


	builder.Register(c => new LoggingActionFilter(c.Resolve<ILogger<LoggingActionFilter>>()))
		.AsWebApiExceptionFilterForAllControllers()
		.InstancePerRequest();

	builder.RegisterApiControllers(Assembly.GetExecutingAssembly());
	var config = GlobalConfiguration.Configuration;
	builder.RegisterWebApiFilterProvider(config);


	var container = builder.Build();
	config.DependencyResolver = new AutofacWebApiDependencyResolver(container);

	//清除 web api xml
	GlobalConfiguration.Configuration.Formatters.XmlFormatter.SupportedMediaTypes.Clear();

}

接著把要用 Log 的類別改成這樣即可

public class LoggingActionFilter : IAutofacExceptionFilter
{
	readonly ILogger<LoggingActionFilter> _logger;

	public LoggingActionFilter(ILogger<LoggingActionFilter> logger)
	{
		_logger = logger;
	}

	public Task OnExceptionAsync(HttpActionExecutedContext actionExecutedContext, CancellationToken cancellationToken)
	{
		_logger.LogError(actionExecutedContext.Exception.Message.ToString());
		return Task.FromResult(0);
	}
}

然後 Controller 大概改這樣 , action 裡面的實作就自行調整

[RoutePrefix("api/ha")]
public class HaController : ApiController
{
	readonly ILogger<HaController> _logger;
	public HaController(ILogger<HaController> logger)
	{
		_logger = logger;
	}

	[HttpGet]
	[Route("ha")]
	public IHttpActionResult Ha()
	{
		_logger.LogError("測試 controller & action");

		try
		{
			throw new Exception("test");
			List<string> list = new List<string>();
			list.Add("haha");
			return Ok(list);
		}
		catch (Exception ex)
		{
			_logger.LogError(ex.ToString());
			return StatusCode(HttpStatusCode.InternalServerError);
		}
	}
}

後來遇到一個雷用 Json 當 Layout 時出現中文亂碼 , 加上 escapeUnicode="false" 還有設定 encoding="utf-8"

<?xml version="1.0" encoding="utf-8" ?>
<nlog xmlns="http://www.nlog-project.org/schemas/NLog.xsd"
      xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
      xsi:schemaLocation="http://www.nlog-project.org/schemas/NLog.xsd NLog.xsd"
      autoReload="true"
      throwExceptions="false"
      internalLogLevel="Off" internalLogFile="c:\temp\nlog-internal.log">

	<extensions>
		<add assembly="NLog.Web"/>
	</extensions>


	<!-- optional, add some variables
  https://github.com/nlog/NLog/wiki/Configuration-file#variables
  -->
	<variable name="myvar" value="myvalue"/>

	<!--
  See https://github.com/nlog/nlog/wiki/Configuration-file
  for information on customizing logging rules and outputs.
   -->
	<targets>

		<!--
    add your targets here
    See https://github.com/nlog/NLog/wiki/Targets for possible targets.
    See https://github.com/nlog/NLog/wiki/Layout-Renderers for the possible layout renderers.
    -->

		<!--
    Write events to a file with the date in the filename.
    <target xsi:type="File" name="f" fileName="${basedir}/logs/${shortdate}.log"
            layout="${longdate} ${uppercase:${level}} ${message}" />
    -->
		<target name="file" xsi:type="File"
			layout="${longdate} ${logger} ${message}${exception:format=ToString}"
			fileName="${basedir}/logs/${shortdate}.log"
			encoding="utf-8" />

		<target name="jsonfile" xsi:type="File" fileName="${basedir}/logs/${shortdate}.json" encoding="utf-8">
			<layout xsi:type="JsonLayout">
				<attribute name="time" layout="${date:format=O}" />
				<attribute name="message" layout="${message}" escapeUnicode="false"/>
				<attribute name="logger" layout="${logger}"/>
				<attribute name="level" layout="${level}"/>

				<attribute name="${aspnet-appbasepath}" layout="${aspnet-appbasepath}"/>
				<attribute name="${aspnet-application}" layout="${aspnet-application}"/>
				<attribute name="${aspnet-item}" layout="${aspnet-item}"/>
				<attribute name="${aspnet-mvc-action}" layout="${aspnet-mvc-action}"/>
				<attribute name="${aspnet-mvc-controller}" layout="${aspnet-mvc-controller}"/>
				<attribute name="${aspnet-request}" layout="${aspnet-request}"/>
				<attribute name="${aspnet-request-cookie}" layout="${aspnet-request-cookie}"/>
				<attribute name="${aspnet-request-form}" layout="${aspnet-request-form}"/>
				<attribute name="${aspnet-request-headers}" layout="${aspnet-request-headers}"/>
				<attribute name="${aspnet-request-host}" layout="${aspnet-request-host}"/>
				<attribute name="${aspnet-request-ip}" layout="${aspnet-request-ip}"/>
				<attribute name="${aspnet-request-method}" layout="${aspnet-request-method}"/>
				<attribute name="${aspnet-request-posted-body}" layout="${aspnet-request-posted-body}"/>
				<attribute name="${aspnet-request-querystring}" layout="${aspnet-request-querystring}"/>
				<attribute name="${aspnet-request-referrer}" layout="${aspnet-request-referrer}"/>
				<attribute name="${aspnet-request-routeparameters}" layout="${aspnet-request-routeparameters}"/>
				<attribute name="${aspnet-request-url}" layout="${aspnet-request-url}"/>
				<attribute name="${aspnet-request-useragent}" layout="${aspnet-request-useragent}"/>
				<attribute name="${aspnet-response-statuscode}" layout="${aspnet-response-statuscode}"/>
				<attribute name="${aspnet-session}" layout="${aspnet-session}"/>
				<attribute name="${aspnet-sessionid}" layout="${aspnet-sessionid}"/>
				<attribute name="${aspnet-traceidentifier}" layout="${aspnet-traceidentifier}"/>
				<attribute name="${aspnet-user-authtype}" layout="${aspnet-user-authtype}"/>
				<attribute name="${aspnet-user-identity}" layout="${aspnet-user-identity}"/>
				<attribute name="${aspnet-user-isauthenticated}" layout="${aspnet-user-isauthenticated}"/>
				<attribute name="${aspnet-webrootpath}" layout="${aspnet-webrootpath}"/>
				<attribute name="${iis-site-name}" layout="${iis-site-name}"/>
			</layout>
		</target>

	</targets>

	<rules>
		<!-- add your logging rules here -->

		<!--
    Write all events with minimal level of Debug (So Debug, Info, Warn, Error and Fatal, but not Trace)  to "f"
    <logger name="*" minlevel="Debug" writeTo="f" />
    -->
		<logger name="*" minlevel="Debug" writeTo="file" />
		<logger name="*" minlevel="Debug" writeTo="jsonfile" />
	</rules>
</nlog>

為了讓 Error 統一輸出自己想要的格式參考這篇

public class GlobalExceptionHandler : ExceptionHandler
{
	//要順便 Log 的話加上去
	//public ILogger<GlobalExceptionHandler> Logger { get; set; }
	public override void Handle(ExceptionHandlerContext context)
	{
		//Logger.LogError(context.Exception.ToString());

		var info = new ErrorInformation
		{
			Message = "伺服器內部發生錯誤" ,
			ErrorDate = DateTime.UtcNow
		};
		var result = context.Request.CreateResponse( HttpStatusCode.InternalServerError, info,
					System.Net.Http.Formatting.JsonMediaTypeFormatter.DefaultMediaType);
		context.Result = new ResponseMessageResult(result);
	}
}

看看要不要順便也把 Log 插裡面 , 要的話需要用 di container 去拿

1 2	builder.RegisterType<GlobalExceptionHandler>().PropertiesAutowired(); config.Services.Replace(typeof(IExceptionHandler), container.Resolve<GlobalExceptionHandler>());

如果不用 DI 拿的話 config 記得要多加上這樣

1	config.Services.Replace(typeof(IExceptionHandler), new GlobalExceptionHandler());

其他地雷

如果有遇到噴這個 error 就檢查看看型別是否設定有錯誤

1
2

None of the constructors found with 'Autofac.Core.Activators.Reflection.DefaultConstructorFinder' on type 'WebApplication3.BoxService' can be invoked with the available services and parameters:
Cannot resolve parameter 'WebApplication3.BoxRepo boxRepo' of constructor 'Void .ctor(WebApplication3.BoxRepo)'.

建構子有問題

Cannot choose between multiple constructors with equal length 2 on type 'WebApplication3.BoxService'. Select the constructor explicitly, with the UsingConstructor() configuration method, when the component is registered.

這兩個順序會讓 autofac 搞不懂要找誰 , 老 code 特別容易發生這種問題

public BoxService( IRepo boxRepo, ILogger logger )
{
	_boxRepo = boxRepo;
	_logger = logger;
}

public BoxService( ILogger logger ,IRepo boxRepo )
{
	_boxRepo = boxRepo;
	_logger = logger;
}

使用 UsingConstructor 告訴他建構子用哪個即可搞定

1
2
3

builder.RegisterType<BoxService>().As<IBoxService>()
	.UsingConstructor(typeof(IRepo) , typeof(ILogger))
	.PropertiesAutowired().InstancePerRequest();

SignalR

官方文件好像沒更新 , 應該是要安裝 Autofac.SignalR2 以及 Autofac.Owin

1	Install-Package Autofac.SignalR2 -Version 6.0.0

這裡特別要注意到 , 如果整合 asp.net webform 的話 , DI 的設定是直接寫在 Global 裡面 , 而 SignalR 則是寫在 Startup 類別裡

public class Startup
{
	public void Configuration( IAppBuilder app )
	{
		var builder = new ContainerBuilder();

		builder.RegisterHubs( Assembly.GetExecutingAssembly() );

		//註冊繼承自 NLog 把建構子改為 public 的自訂類別
		builder.RegisterType<MyLogger>().As<ILogger>();

		//註冊 repository
		builder.RegisterType<BoxRepo>().As<IRepo>();

		//設定 services
		builder.RegisterType<BoxService>().As<IBoxService>()
			.UsingConstructor( typeof( IRepo ), typeof( ILogger ) );
			//.InstancePerLifetimeScope();

		var container = builder.Build();
		var resolver = new AutofacDependencyResolver( container );

		// Any connection or hub wire up and configuration should go here
		app.UseAutofacMiddleware(container);

		app.Map( "/signalr", map =>
		{
			map.UseCors( CorsOptions.AllowAll );
			var config = new HubConfiguration { Resolver = resolver };
			map.RunSignalR(config);
		} );

	}
}

接著注入物件到 hub 內

public class TestHub : Hub
{
	private readonly ILifetimeScope _hubLifetimeScope;
	private readonly ILogger _logger;
	private readonly IBoxService _boxService;

	//可以這樣寫
	//public TestHub( ILifetimeScope lifetimeScope )
	//{
	//    // Create a lifetime scope for the hub.
	//    _hubLifetimeScope = lifetimeScope.BeginLifetimeScope();

	//    // Resolve dependencies from the hub lifetime scope.
	//    _logger = _hubLifetimeScope.Resolve<ILogger>();

	//    _boxService = _hubLifetimeScope.Resolve<IBoxService>();
	//}

	//這樣寫也可以
	public TestHub(IBoxService boxService , ILogger logger)
	{
		_boxService = boxService;
		_logger = logger;
	}


	//給 client 呼叫 server 上的方法
	public void LaSai( string message )
	{
		_logger.Info( "test log" );
		var result = _boxService.GetAll();
		//server 丟一些 result 回去給 client
		Clients.All.hello( result );
	}
}

最後是前端呼叫 laSai 這個方法時 , 因為在 server 內有這句 Clients.All.hello( result ); 所以前端會把得到的 json 物件印在畫面上

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8" />
    <title></title>
    <script src="Scripts/jquery-3.4.1.js"></script>
    <script src="Scripts/jquery.signalR-2.2.2.js"></script>
    <script src="/signalr/hubs"></script>

	<!--使用靜態生出來的-->
    <!--<script src="Scripts/server.js"></script>-->
</head>
<body>
    <script>

		//如果是其他站台要用的話要加上這句
		//$.connection.hub.url = 'http://localhost:23007/signalr';
        var chat = $.connection.testHub;

        $.connection.hub.start().done(function () {
            $(document).on('click' , '#btn', function () {
                chat.server.laSai('la di sai');
            })
        })

        chat.client.hello = function (resp) {
            console.log(resp);
            resp.forEach(x => {
                $('#display').append(`<p>${x.Name}</p>`);
            });
        }
    </script>
    <div id="display"></div>
    <button id="btn">go</button>
</body>
</html>

SignalR 後續

常常有個疑惑 , 不曉得怎樣定時去撈 DB 然後用 signalr 傳給前端 , 於是看到了這篇文章
主要就是實現了 IRegisteredObject 介面 , 然後就可以在 server 裡面定時去執行某些任務
所以特別注意到 HostingEnvironment.RegisterObject 當插入這個以後 server side (IIS) 就會固定每隔 N 秒執行撈 sql 的動作

另外有個雷 , 因為我有用 autofac 導致執行的時候雖然會觸發 timer 內的事件 , 結果 signalr server side 裡面的 function 卻不 work
所以要參考這篇去調整設定 , 不然是吃不到 DI 的

Startup 內的 Configuration 方法

var builder = new ContainerBuilder();

//註冊 signalr 的 hub
builder.RegisterHubs(Assembly.GetExecutingAssembly());

//把 NLog 的 Provider 新增進去
var loggerFactory = new LoggerFactory();
loggerFactory.AddProvider(new NLogLoggerProvider());

//註冊 AutoMapper
builder.RegisterAutoMapper(Assembly.GetExecutingAssembly());
builder.RegisterType(typeof(Mapper)).AsSelf();

//這行是必須的
builder.RegisterInstance(loggerFactory).As<ILoggerFactory>().SingleInstance();

//用泛型註冊
builder.RegisterGeneric(typeof(Logger<>)).As(typeof(ILogger<>));


//DI 的相關屬性設定
//註冊 connectionFactory
builder.RegisterType<ConnectionFactory>()
	.As<IConnectionFactory>()
	.AsSelf();

//註冊 repository
builder.RegisterType<YourRepository>()
	.As<IYourRepository>()
	.As<IRepository<YourClass>>()
	.AsSelf();

var container = builder.Build();
var resolver = new AutofacDependencyResolver(container);

//todo 注意這個地方很雷 , 如果沒有替換 DependencyResolver 會無法正常 trigger 10 秒更新軌跡的動作
//https://stackoverflow.com/questions/21126624/signalr-autofac-owin-why-doesnt-globalhost-connectionmanager-gethubcontext
GlobalHost.DependencyResolver = resolver;

var yourService = resolver.Resolve<YourService>();

// Any connection or hub wire up and configuration should go here
app.UseAutofacMiddleware(container);

//設定 signalr
app.Map("/signalr", map =>
{
   map.UseCors(CorsOptions.AllowAll);

   //這裡直接插 config 會失效
   //var config = new HubConfiguration { Resolver = resolver };

   //要選用這個方法
   //map.MapHubs(config);

   //如果直接用這句的話不曉得為啥會不給過 , 可能是 autofac 跟 signalr 整合的 bug
   //map.RunSignalR(config);

   //同上面的問題 GlobalHost.DependencyResolver , 上面三句在此處其實都不起作用  , 直接呼叫 RunSignalR 即可
   map.RunSignalR();
});

//註冊背景物件 , 這個會去定時每隔 10 秒呼叫一次 hub
//撈 sql 把資料給送給前端使用
HostingEnvironment.RegisterObject(new BackgroundServerTimer(yourService));

web api

autofac

Autofac.WebApi2

1	Install-Package Autofac.WebApi2 -Version 6.1.0

一樣在 Global 設定 , 這次不小心踩個雷 , 把 builder.RegisterApiControllers( Assembly.GetExecutingAssembly() ).InstancePerRequest(); 寫在 var container = builder.Build(); 之後
特別注意這個順序很重要 , 寫錯了就起不來 , 讓你 debug 到想死 , 可憐 ~

void Application_Start( object sender, EventArgs e )
{
	//設定 DI
	var builder = new ContainerBuilder();

	//DI 的相關屬性設定
	builder.RegisterType<MyLogger>().As<ILogger>().InstancePerRequest();
	builder.RegisterType<BoxRepo>().As<IRepo>().InstancePerRequest();
	builder.RegisterType<BoxService>().As<IBoxService>()
		.UsingConstructor( typeof( IRepo ), typeof( ILogger ) )
		.PropertiesAutowired().InstancePerRequest();

	//設定 web api controller 註冊 DI
	builder.RegisterApiControllers( Assembly.GetExecutingAssembly() ).InstancePerRequest();

	//建立 DI container 特別注意順序很重要 , build 完以後才寫上面的屬性註冊會失效
	var container = builder.Build();

	//註冊給 asp.net webform 使用
	_containerProvider = new ContainerProvider( container );

	//設定 web api 的 di
	var config = GlobalConfiguration.Configuration;
	config.DependencyResolver = new AutofacWebApiDependencyResolver( container );

	//預設的 application startup 設定流程
	GlobalConfiguration.Configure( WebApiConfig.Register );
	RouteConfig.RegisterRoutes( RouteTable.Routes );
	BundleConfig.RegisterBundles( BundleTable.Bundles );

	//清空 xml formatter
	GlobalConfiguration.Configuration.Formatters.XmlFormatter.SupportedMediaTypes.Clear();
}

WebApiProxy

在 nuget 搜尋 WebApiProxy 並且安裝
找到 WebApiConfig 加上這句 config.RegisterProxyRoutes( );
參考自這篇

private static void AddRoutes(HttpConfiguration config)
{
    //https://dotblogs.com.tw/yc421206/2018/09/28/webapi_generate_proxy_class_code
    //WebApiProxy
    config.RegisterProxyRoutes( );

    //這串要在 MapHttpRoute 前面
    config.MapHttpAttributeRoutes( );

    config.Routes.MapHttpRoute(
        name: "DefaultApi",
        routeTemplate: "api/{controller}/{id}",
        defaults: new { id = RouteParameter.Optional }
    );
}

他會幫你自動產生 proxy 像這樣 http://localhost:23007/api/proxies
接著前端 code 會長這樣 , 注意需要有 jQuery

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8" />
    <title></title>
    <script src="Scripts/jquery-3.4.1.js"></script>

    <!--自動產生的 javascript api proxies-->
    <script src="/api/proxies"></script>

</head>
<body>
    <script>
        //測試 proxy 產出的 javascript api
        $.proxies.gps.get('test2').done(function (resp) {
            console.log(resp);
        });

        var test1 = {
            "id": 'test1',
            "x": 12,
            "y": 24,
        };
        $.proxies.gps.add(test1).done(function (resp) {
            console.log(resp);
        });

    </script>
</body>
</html>

Swashbuckle

在 nuget 搜尋 Swashbuckle 並且安裝
Build => Output path => bin\ => 打勾 XML document file => bin\WebApplicationWebFormWithWebApi.xml
找到 SwaggerConfig.cs 底下的 c.IncludeXmlComments 這串 , 修改為這樣
參考1 參考2 參考3

var files = Directory.GetFiles(
	AppDomain.CurrentDomain.BaseDirectory, $"WebApplicationWebFormWithWebApi*.xml",
	SearchOption.AllDirectories
);
foreach (var name in files) c.IncludeXmlComments( name );

生出 typescript 用的前端 api

這個是因為用純 js 太通靈 , 後來才發現的 typescript 方法 , 需要先有 swagger 的 api 才可以動!
安裝 , 注意要切到你專案的 root 底下 , 可以參考這個官方說明

1	npm i swagger-typescript-api

建立資料夾讓他長得像是下面這樣

├───Scripts
│   └───TypeScripts
│       ├───dist
│       └───src

接著在 TypeScripts/src 底下新增 tsconfig.json , 這個選項 compileOnSave 可以讓存檔時生出 js 檔案

{
  "compilerOptions": {
    "noImplicitAny": false,
    "noEmitOnError": true,
    "removeComments": false,
    "sourceMap": true,
    "target": "ES2020",
    "outDir": "./dist",
    "rootDir": "./src",
    "module": "ES2020"
  },
  "exclude": [
    "node_modules",
    "wwwroot"
  ],
  "compileOnSave": true
}

最後啟動你的 api 網站 , 讓他能抓得到 swagger 產生的 json , 並且執行以下命令

1	npx swagger-typescript-api -p http://localhost:50348/swagger/docs/v1 -o ./YourProject/Scripts/TypeScripts/src -n myApi.ts

接著 cd 到 TypeScripts 目錄 , 執行 tsc 這個命令讓 js 可以生出來 , 注意一定要在 TypeScripts 這個資料夾才正常

tsc

在 Solution Exploer 上面點 Show All Files 可以看到生出 myApi.ts

1	tsc myApi.ts

萬一跳這個 error 執行這串即可 npm install -g typescript

tsc : 無法辨識 'tsc' 詞彙是否為 Cmdlet、函數、指令檔或可執行程式的名稱。請檢查名稱拼字是否正確，如果包含路徑的話，請確認路徑是否正確，然後再試一次。

在 src 加入這個檔案 test.ts

import { Api } from "./myApi.js";

const root = new Api({
    baseUrl: "http://localhost:50348"
});


var test = root.api.valuesGet();

root.api.valuesGet().then(x => console.log(x.data));

最後新增個網頁來測 test.html , 正常的話在 console 上面會印出 api 撈出的數值 , 這樣可以用強行別減輕不少開發壓力

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8" />
    <title></title>
</head>
<body>
    <script src="Scripts/TypeScripts/src/test.js" type="module"></script>
</body>
</html>

整合 AutoMaper

首先安裝 AutoMapper 及 AutoMapper.Contrib.Autofac.DependencyInjection
可以參考他的官網

修正 Global 如下就可以正常註冊了 , 他的 github 上面 example 好像沒更新
他是用這句 containerBuilder.AddAutoMapper(typeof(Program).Assembly); 實際使用時看他標示已經棄用

 public class Global : HttpApplication, IContainerProviderAccessor
 {
     static IContainerProvider _containerProvider;
     public IContainerProvider ContainerProvider
     {
         get { return _containerProvider; }
     }
     void Application_Start( object sender, EventArgs e )
     {
         var builder = new ContainerBuilder();

         //註冊 AutoMapper
         builder.RegisterAutoMapper( Assembly.GetExecutingAssembly() );
//我測 webform 沒加這句的話也會噴 null
builder.RegisterType(typeof(Mapper)).AsSelf();

         builder.RegisterType<MyLogger>().As<ILogger>().InstancePerRequest();
         builder.RegisterApiControllers( Assembly.GetExecutingAssembly() ).InstancePerRequest();
         var container = builder.Build();
         _containerProvider = new ContainerProvider( container );
         var config = GlobalConfiguration.Configuration;
         config.DependencyResolver = new AutofacWebApiDependencyResolver( container );

         //從 Autofac 裡面拿出 AutoMapper 的 config
         var mapperConfiguration = container.Resolve<MapperConfiguration>();

         //這句用來驗證 AutoMapper 的 Profile 是否正確
         mapperConfiguration.AssertConfigurationIsValid(  );

         // Code that runs on application startup
         GlobalConfiguration.Configure( WebApiConfig.Register );
         RouteConfig.RegisterRoutes( RouteTable.Routes );
         BundleConfig.RegisterBundles( BundleTable.Bundles );
     }
 }

建立 Customer

public class Customer
{
	public Guid Id { get; }
	public string Name { get; }

	public Customer( Guid id, string name )
	{
		Id = id;
		Name = name;
	}
}

建立 CustomerDto

public class CustomerDto
{
	public Guid Id { get; }
	public string Name { get; }

	public string FullName { get; set; }

	public CustomerDto( Guid id, string name )
	{
		Id = id;
		Name = name;
	}
}

建立 CustomerProfile
這裡是重點 , 最好在專案建立資料夾 Profiles 進行分類 , 不然會有一堆 mapping
注意他的規則是擺在後面的 Type 為 return 的物件 , 所以此處為設定 CustomerDto 為 return 的結果
如果屬性相同的話可以不用一個一個設定 , 他會自己去 mapping
最後可以考慮加上 ReverseMap(); 這樣可以 two way mapping

public class CustomerProfile : Profile
{
	public CustomerProfile()
	{
		//注意他的規則是擺在後面的 Type 為 return 的物件
		//從 Customer 的 Name +Id Mapping 至 DTO 的 FullName
		CreateMap<Customer, CustomerDto>()
			.ForMember( x => x.FullName, y => y.MapFrom( z => z.Id + z.Name ) )
			.ReverseMap();
	}
}

最後弄個 api controller 測試看看 , 要手動注入 IMapper 就搞定了

[RoutePrefix("api/values")]
public class ValuesController : ApiController
{
	private readonly IComponentContext _componentContext;
	private readonly IMapper _mapper;
	public ValuesController( IComponentContext componentContext, IMapper mapper )
	{
		_componentContext = componentContext;
		_mapper = mapper;
	}

	[HttpGet]
	[Route("test")]
	public string Get()
	{
		Debug.WriteLine("Hello World");
		var x = _componentContext.Resolve<ILogger>(new TypedParameter(typeof(string) , "test test test test"));
		x.Info( "Ha Ha" );

		return "test";
	}

	[HttpGet]
	[Route("CustomerToDto")]
	public CustomerDto CustomerToDto()
	{
		var customer = new Customer( Guid.NewGuid(), "HaHa" );
		var result = _mapper.Map<Customer, CustomerDto>(customer);
		return result;

	}

	[HttpGet]
	[Route("DtoToCustomer")]
	public Customer DtoToCustomer()
	{
		var customerDto = new CustomerDto( Guid.NewGuid(), "HaHa" );
		var result = _mapper.Map<CustomerDto, Customer>(customerDto);
		return result;
	}
}

最後是 signalr 整合 automapper , 跟前面一樣大同小異在 Startup
加入關鍵這三行即可
builder.RegisterAutoMapper( Assembly.GetExecutingAssembly() );
var mapperConfiguration = container.Resolve<MapperConfiguration>();
mapperConfiguration.AssertConfigurationIsValid();

public class Startup
{
	public void Configuration( IAppBuilder app )
	{
		var builder = new ContainerBuilder();

		builder.RegisterAutoMapper( Assembly.GetExecutingAssembly() );

		builder.RegisterHubs( Assembly.GetExecutingAssembly() );
		builder.RegisterType<MyLogger>().As<ILogger>();

		builder.RegisterType<BoxRepo>().As<IRepo>();

		builder.RegisterType<BoxService>().As<IBoxService>()
			.UsingConstructor( typeof( IRepo ), typeof( ILogger ) );
			//.InstancePerLifetimeScope();

		var container = builder.Build();
		var resolver = new AutofacDependencyResolver( container );

		//從 Autofac 裡面拿出 AutoMapper 的 config
		var mapperConfiguration = container.Resolve<MapperConfiguration>();

		//這句用來驗證 AutoMapper 的 Profile 是否正確
		mapperConfiguration.AssertConfigurationIsValid();


		// Any connection or hub wire up and configuration should go here
		app.UseAutofacMiddleware(container);

		app.Map( "/signalr", map =>
		{
			map.UseCors( CorsOptions.AllowAll );
			var config = new HubConfiguration { Resolver = resolver };
			map.RunSignalR(config);
		} );

	}
}

接著建立 CustomerHub

public class CustomerHub : Hub
{
	private readonly IMapper _mapper;

	public CustomerHub( IMapper mapper )
	{
		_mapper = mapper;
	}

	public CustomerDto CustomerToDto()
	{
		var customer = new Customer( Guid.NewGuid(), "HaHa" );
		var result = _mapper.Map<Customer, CustomerDto>( customer );
		Clients.All.getCustomerDto( result );
		return result;

	}

	public Customer DtoToCustomer()
	{
		var customerDto = new CustomerDto( Guid.NewGuid(), "HaHa" );
		var result = _mapper.Map<CustomerDto, Customer>( customerDto );
		Clients.All.getCustomer( result );
		return result;
	}
}

最後調整前端 code

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8" />
    <title></title>
    <script src="Scripts/jquery-3.4.1.js"></script>
    <script src="Scripts/jquery.signalR-2.2.2.js"></script>
    <script src="/signalr/hubs"></script>

	<!--使用靜態生出來的-->
    <!--<script src="Scripts/server.js"></script>-->
</head>
<body>
    <script>
        var chat = $.connection.customerHub;
        $.connection.hub.start().done(function () {
            $(document).on('click' , '#btn', function () {
                chat.server.customerToDto();
            })
        })
        chat.client.getCustomerDto = function (resp) {
            console.log(resp);
            $('#display').append(`<p>${resp.Id} , ${resp.Name}</p>`);
        }
    </script>
    <div id="display"></div>
    <button id="btn">go</button>
</body>
</html>
